TMCM-1111 STEPROCKER
Controller Board, TMC4361, Power Management - Motor Control, 2-Phase Stepper Motor Controller/Driver
Image is for illustrative purposes only. Please refer to product description.
ManufacturerTRINAMIC / ANALOG DEVICES
Manufacturer Part NoTMCM-1111 STEPROCKER
Order Code3804181
Your Part Number
Technical Datasheet
1 In Stock
Need more?
EXPRESS Delivery in 1-2 business days
Order before 5pm
FREE Standard Delivery
on orders €0.00 and above
Accurate delivery times will be calculated at checkout
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | €123.270 |
Price for:Each
Minimum: 1
Multiple: 1
€123.27 (ex VAT)
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
ManufacturerTRINAMIC / ANALOG DEVICES
Manufacturer Part NoTMCM-1111 STEPROCKER
Order Code3804181
Technical Datasheet
Application Sub Type2-Phase Stepper Motor Controller/Driver
Silicon ManufacturerTrinamic
Kit Application TypePower Management - Motor Control
Silicon Core NumberTMC4361
Kit ContentsController Board TMC4361
Product Range-
SVHCNo SVHC (16-Jul-2019)
Product Overview
TMCM-1111 STEPROCKER is a single axis motor controller/driver board for 2-phase bipolar stepper motors. It supports S-shaped ramps in addition to linear ramps and closed-loop operation together with an external encoder. Suitable for highly compact single axis stepper motor controller/driver board for 2-phase bipolar stepper motors, linear and S-shaped ramps and closed-loop operation together with external encoder applications.
- Single axis controller/driver for 2-phase bipolar stepper motor
- S-shaped ramps and linear ramps
- Closed-loop operation with external encoder
- Supply voltage range from +10V DC to 30V DC
- Up to 2.8A RMS motor current
- Multi-purpose inputs and outputs
- Interfaces: RS485 host interface, USB 2.0 host interface (mini-USB CONN), step/Dir input (TTL level)
- 3 multi-purpose I/P(used for incremental ABN-encoder), 6 multi-purpose I/Os, 2 open-drain O/Ps
- START input/output for synchronized motion with several axes
- Board size: 85mm x 55mm, height 15mm max. without mating connector
